Multihead OT.T.T.M.P. IV


same head with 2 pen/marker attachments


This head is available for the ARISTOMAT SL, TL and GL series

Multihead OT.M.P. IV


With only one tangentially controlled tool for either fix or oscillated cutting, a pen/marker attachment, and a laser pointer for registration


This head is available for the ARISTOMAT SL, TL and GL series

ARISTOMAT Router attachment next to the OTTTMP IV


Router attachment with 1000 Watt HF KaVo spindle


This head is available for the ARISTOMAT SL, TL and GL series

ARISTOMAT Router attachment as a stand alone tool


Router attachment with 1000 Watt HF KaVo spindle


This head is available for the ARISTOMAT SL, TL and GL series

ARISTOMAT Router attachment with Automatic registration system


Router attachment with 1000 Watt HF KaVo spindle and camera based


automatic registration system


This head is available for the ARISTOMAT SL, TL and GL series

ARISTOMAT Bevel cut system


This head is available for the ARISTOMAT SL, TL and GL series

ARISTOMAT Motorized rotary wheel cut system


This head is available for the ARISTOMAT SL, TL and GL series

ARISTOMAT OT.T.T.M.P. with Automatic camera registration and Infra cut attachment for creasing Corex or other corrugated plastic materials


This head is available for the ARISTOMAT SL, TL and GL series

Multihead OT.T.T.M.P. IV

with built in Camera registration system

This head is available for the ARISTOMAT SL, TL and GL series

Tool 1 - tangentially controlled, oscillator can be switched on or off

Tool 2 - tangentially controlled, fixed

Tool 3 - tangentially controlled, fixed

Tool 4 - Pen or Marker

Tool 5 - additional Pen or Marker  (optional, here not attached)

Tool 6 - LaserPointer for manual registration

Tool 7 - Automatic  Eye  (camera registration system)

Multihead OT.T.T.M.P.

same head without built-in camera

This head is available for the ARISTOMAT CL, SL, TL and GL series

OT.T.T.M.P. IV

This head is available for the ARISTOMAT CL, SL, TL and GL series

Tool 1 - tangentially controlled, oscillator can be switched on or off

Tool 2 - tangentially controlled, fixed

Tool 3 - tangentially controlled, fixed

Tool 4 - Pen or Marker

Tool 5 - additional Pen or Marker  (optional, here not attached)

Tool 6 - LaserPointer for manual registration

OTMP IV

With only one tangentially controlled tool for either fix or

oscillated cutting, a pen/marker attachment, and a laser pointer for registration

This head is available for the ARISTOMAT CL, SL, TL and GL series

Standard Tool Head

servomotor controlled up and down

Standard DUAL MODE Tool Head

servomotor controlled up and down

Pneumatic Tool Head

pneumatic up and down

Pneumatic Tool Head with Marker attachment

pneumatic up and down

Standard tool head with AutoEye attached

for camera based automatic registration

Router attachment

with 900Watt KRESS spindle

HF ROUTER

High precision engraving spindle
