Knives

Part Nr. / Description

Price for Knives:

Knife holder to

be used:

Price for knife holder:

(placeholder)
(placeholder)
(placeholder)
(placeholder)

Part # 00000.7275

Set of 3 blades 6mm dia.

for 5mm cutting depth

for tool 1 Oscillating, holder 7553

Part # 00000.7267

blade 6mm dia. for 10mm depth

for tool 1 Oscillating, holder 7553

Part # 00000.7265

blade 6mm dia. for 15mm depth

for tool 1 Oscillating, holder 7553

Nr. 00000.7553

$ 240.00 ea.

$ 29.00 ea.

Knives and Accessories for the MULTI HEAD

For Multihead

OTMP, OTTMP, OTTTMP

$ 150.00 p.set

($ 50.00 ea.)

$ 55.00 ea.

$ 60.00 ea.

(placeholder)
(placeholder)
(placeholder)

Part # 00000.7354

blade 8mm dia. for 25mm depth

for tool 1 Oscillating,  no holder needed

Part # 00000.7394

blade 8mm dia. for 30mm depth

for tool 1 Oscillating, no holder needed

Part # 00000.7395

blade 8mm dia. for 35mm depth

for tool 1 Oscillating, no holder needed

$ 90.00 ea.

$ 140.00 ea.

$ 145.00 ea.

used without tool holder in Aristo cutters

an 8mm to 6mm Adapter

is available if your machine has a 6mm opening

$ 290.00 ea.

Part # 00000.4545

set of 5 blades 70 degr. with flat tip

7mm cut depth,  for soft fibrous materials (leather, fabric, foam)

for tool 1 Oscillating, tool holder 4540

$ 185.00 p.set

($ 37.00 ea.)

(placeholder)

Nr. 00000.4540

$ 450.00 ea.

Part # 910.313

set of 5 blades Z20, 65/85 degr.,

10mm cut depth,  for rubber, foam, corrugated panels etc.

for tool 1 Oscillating,  tool holder 4560

$ 150.00 p.set

($ 30.00 ea.)

Nr. 00000.4560

$ 450.00 ea.

(placeholder)
(placeholder)

Part # 910.314

set of 5 blades Z21, 65/85 degr.,

13mm cut depth,  for rubber, foam, corrugated panels etc.

for tool 1 Oscillating, tool holder 4560

$ 150.00 p.set

($ 30.00 ea.)

Part # 910.315

set of 5 blades Z22, 65/80 degr.,

for rubber, foam, up to 13mm, or solid boards up to 3mm,

for tool 1 Oscillating, tool holder 4560

$ 150.00 p.set

($ 30.00 ea.)

(placeholder)

Part # 910.324

set of 5 blades Z42, -15/55 degr.,

5mm cut depth, special tip for cutting fabrics, leather etc.

for tool 1 Oscillating

tool holder Nr.7085, (6mm)

or 7111 (3mm) oscillating only

$ 170.00 p.set

($ 34.00 ea.)

Nr. 00000.7085



$ 695.00 ea.


special order



(placeholder)

Part # 910.306-L

set of 5 blades solid carbide

55 degr. single edge, up to 5mm cut depth, for folding carton applications -

drag knife holder 7563

or oscillating holders 7085 or 7111


$ 150.00 p.set

($ 30.00 ea.)

(placeholder)

Part Nr. 910.301-S

Set of 3 solid carbide blades

type WIDIA, dual edge,

50 degr.cut angle, 20 degr. wedge

for folding carton, plastics etc.

for tool holder Nr. 4520 (drag knife)

or holder Nr. 4550 (oscillating knife)

$ 96.00 p.set ($ 32.00 ea.)

(placeholder)

Part Nr. 910.309-S

Set of 3 solid carbide blades

type WIDIA, dual edge,

60 degr.cut angle, 20 degr. wedge

for folding carton, plastics etc.

for tool holder Nr. 4520 (drag knife)

or holder Nr. 4550 (oscillating knife)

$ 96.00 p.set ($ 32.00 ea.)

(placeholder)

Oscillating

Nr. 00000.4550

$ 450.00 ea.

$ 580.00 ea.

Non-Oscillating

Nr. 00000.4520

Part Nr. 4800.073-AR35

Set of 3 solid carbide blades Z46 AR

45/90 degr.cut angle,

drag knife for foam boards, carpet and thick fibrous materials

for tool holder Nr. 4570

$ 138.00 p.set ($ 46.00 ea.)

(placeholder)

$ 450.00 ea.

Nr. 00000.4570

Part # 999.511

set of 10 blades, type 1

40/40 degr.,  single edge

for kiss-cutting vinyl, small letters

tool holder Nr. 4500

$ 240.00 p.set

($ 24.00 ea.)

Nr. 00000.4500

(placeholder)

Part # 999.512

set of 10 blades, type 2

30/40 degr. , single edge

for kiss-cutting vinyl, small letters

tool holder Nr. 4500

$ 240.00 p.set

($ 24.00 ea.)

Part # 999.513

set of 10 blades, type 3

40/30 degr.  , dual edge

for kiss-cutting vinyl and masks

tool holder Nr. 4500

$ 250.00 p.set

($ 25.00 ea.)

(placeholder)
(placeholder)

Part # 999.514

set of 10 blades, type 4

26/54 degr.  solid carbide

for kiss-cutting thick vinyl

tool holder Nr. 4500

$ 240.00 p.set

($ 24.00 ea.)

Part # 999.515

set of 10 blades, type 5

30/30 degr.  solid carbide

best performer for most kiss-cutting applications  -  tool holder Nr. 4500

$ 250.00 p.set

($ 25.00 ea.)

(placeholder)

$ 580.00 ea.

(placeholder)

Nr. 00000.7563

$ 560.00 ea.

(placeholder)

Part # 00000.7713

set of 10 flat steel  blades Martor Nr. 679,  5mm cut depth,

for tool 1,  Oscillating

$ 25.00 p.set

($ 2.50 ea.)

Nr. 00000.7200

$ 560.00 ea.

(placeholder)

Part # 00000.7568

set of 10 flat steel  blades

Boy Nr. 72,  70 degr. cut angle


10mm cut depth,

for tool,  1 Oscillating

Nr. 00000.7567

$ 610.00 ea.


10mm cut depth,

for tool 2 or 3,  Non-Oscillating

(placeholder)

Nr. 00000.7479

$ 780.00 ea.

$ 25.00 p.set

($ 2.50 ea.)

(placeholder)

Part Nr. 00000.7263

Set of 5 circular blades,

25mm dia. , 0.6mm thick


for holder with 14mm disk

$ 75.00 p.set

($ 15.00 ea.)

Nr. 00000.7031

$ 836.00 ea.


special order

(placeholder)





for holder with 18mm disk

Nr. 00000.7018

$ 945.00 ea.


special order

(placeholder)

Part Nr. 00000.7077

Set of 5 circular blades,

25mm dia. , 0.3mm thick


for holder with 25mm rubber disk

$ 70.00 p.set

($ 14.00 ea.)

Nr. 00000.7078

$ 895.00 ea.


special order

(placeholder)

Part Nr. 00000.7022

Set of 10 punching blades

$ 48.00 p.set

($ 4.80 ea.)

Nr. 00000.7020

$ 480.00 ea.


special order

(placeholder)

Part Nr. 00000.7130

Set of 10 knives

30/16 degr. single edge

for masking films

not for kiss-cutting with holder 7262

$ 240.00 p.set ($ 24.00 ea.)

Nr. 00000.7262

(placeholder)
(placeholder)

Part Nr. 00000.7131

Set of 10 knives

35/40 degr. single edge

for Vinyl and polyester films

not for kiss-cutting with holder 7262

Part Nr. 00000.7864

Set of 10 knives

30/60 degr. single edge

for thicker materials and stencils

not for kiss-cutting with holder 7262

(placeholder)
(placeholder)

Part Nr. 00000.7750

Set of 10 knives

30/40 degr. dual edge

for reflective materials

not for kiss-cutting with holder 7262

Part Nr. 00000.7132

Set of 10 knives

24/64 degr. dual edge

for thicker films and reflectives

not for kiss-cutting with holder 7262

(placeholder)

$ 640.00 ea.

(placeholder)

Part Nr. 999.529

Set of 10 knives 26/40 degr. dual edge

30mil thin,  for thicker films, reflectives and Polyester -

not for kiss-cutting with holder 7262


Part Nr. 999.530

Set of 10 knives

26/54 degr. dual edge

30mil thin,  for thicker films, and folding carton -

not for kiss-cutting with holder 7262

(placeholder)

Part Nr. 999.534

Aristo knife changer tool

(tweezer)

(placeholder)

$ 57.00 ea.



(placeholder)

Part Nr. 00000.7572

Spare downholder for oscillating tool of Multi head

Part Nr. 2151.32055

Delrin Ring only for

oscillating downholder for Multi head

(placeholder)

$ 290.00 ea.

outside view

inside view

Part Nr. 00000.7704

Creasing wheel for folding carton

2 pt.


$ 115.00 ea.

Nr. 00000.7711

$ 580.00 ea.

(placeholder)

Part Nr. 00000.7705

Creasing wheel for folding carton

3 pt.


$ 110.00 ea.

Part Nr. 00000.7706

Creasing wheel for folding carton

4 pt.


$ 110.00 ea.

(placeholder)
(placeholder)

Part Nr. 00000.7562

Creasing wheel for folding carton

4 pt.


$ 220.00 ea.

(placeholder)

Part Nr. 00000.7496

Creasing wheel for Plastics



$ 110.00 ea.

Nr. 00000.7560

$ 580.00 ea.

Nr. 00000.7490

$ 580.00 ea.

Part Nr. 00000.7707

Creasing wheel for corrugated

cardboard R 1.5,

F and E-Flute



$ 115.00 ea.

Part Nr. 00000.7708

Creasing wheel for corrugated

cardboard R 3.3

B and BC-Flute



$ 110.00 ea.

(placeholder)
(placeholder)

Part Nr. 00000.7709

Creasing wheel for corrugated

cardboard R 7.0

C-Flute



$ 110.00 ea.

(placeholder)

Part Nr. 00000.7357

100 degr. double crease wheel

0.6 mm



$ 122.00 ea.

(placeholder)

1/8” Punching tool (3.2mm)



$ 95.00 ea.

1/4” Punching tool  (6.4mm)



$ 95.00 ea.

(placeholder)
(placeholder)

5/16” Punching tool  (7.9mm)



$ 95.00 ea.

(placeholder)

3/8” Punching tool  (9.5mm)



$ 95.00 ea.

(placeholder)

Nr. 00000.7144

$ 350.00 ea.

(placeholder)

Punching wheels available on request only

not in stock

Nr. 00000.7111

$ 560.00 ea.


5mm cut depth, Non-Oscillating, drag knife


Part # 00000.7264

set of 10 flat steel  blades Martor Nr. 784, 50 degr.  single edge

general purpose knife

drag knife holder 7563

or oscillating holders 7085 or 7111



$ 25.00 p.set

($ 2.50 ea.)

6mm cut depth,   Oscillating

3mm cut depth,  Oscillating
